Characteristics
- Single channel Ethernet and power extender over network cable
- Support cascade mode; maximun four transmitters can be cascaded
- Ethernet transmission distance max up 600 meters
- 12 Watts output power
- Meet standards of IEEE802.3 10 BASE-T IEEE802.3U 100BASE-TX
- High-speed modem technology, the physical bandwith reaches up to 100Mbps ( Bidirectional )
- Low power consuption, automatic error-correction coding technology
- Easy to install, plug and play, fast network connection
Physical and Electrical Characteristics
- Power supply : 53VDC/1.85A (incluided for the receiver)
- Dimensions: 123 x 54 x 24 mm
- Weight: 129 gr Transmitter
- Operating temperature : 0 a 55°C
- Humidity : 0 ~ 95% (without condenation)
- Body color: Black
- Housing: Aluminium
Applications
- Security monitoring system
- Banking, securities, financial
- Casino Security
- Hospitals, Airports
- University, School campus
